Four cameras, a Wi-Fi DVR with a Western Digital 1TB hard drive, and four power adapters DC 12V / 1.5 A for separate camera power supplies are all included in the surveillance kit. When video data is recorded utilizing the H.264 video compression standard, the best possible image quality can be obtained with the least amount of disk storage and network transfer. The menu options structure has been created with all users in mind; even novices will find it easy to explore and make changes to the DVR settings.

Features of his 4-Channel HD camera 4MP Wi-Fi Kit

Hikvision WiFi Camera
Connects to the recorder via WiFi, so there’s no need to run cables between the devices. Perfect for large properties or installations that need to be moved around. Provides a range of up to 50 metres

4-Megapixel Video
Unlike traditional wireless cameras with low resolutions, these cameras record 2688×1520 video, with twice the detail of even Full HD, at 20 frames per second

High Resolution Video
Outputs video with over twice the detail of Full HD, for recording and viewing on an NVR

30m Night Vision
Uses infrared LEDs to clearly record subjects after dark, even in larger outdoor spaces. Up to 30 metres of night vision range

IP66-Rated
Dome housings not only keep cameras discreet, but are completely weatherproof, allowing outdoor use

Wide Angle Lens
2.8mm lens records everything in a 103° arc in front of the camera

One-time Configuration– Connect camera to recorder using the included patch cable for a one-time setup, then the camera can be used over wifi with no network cable

Automated Network Recovery
Cameras include a MicroSD card slot, which can be set up as an automated backup in case the recorder loses connection. Cards not included

Wide Dynamic Range
Setting allows enhanced highlight and shadow sensitivity, so it adjusts the image automatically to eliminate areas of underexposure and overexposure, helping preserve detail in high-contrast lighting conditions such as windows

Smart Detection
Allows the use of Hikvision’s latest automation features, including line crossing, object removal and intrusion detection

On-board Recording
Features a built-in MicroSD slot for recording. Supports cards up to 128GB

Smartphone Connectivity
Remote access allows you to connect into the camera using an app on your smartphone

H.265+ Compression
Sends video compressed using H.265+ technology so that higher quality footage can be stored using a more efficient amount of capacity

Sub Streams
Captures full resolution footage whilst simultaneously streaming lower resolution images to PC & mobile devices

Audio & Alarm Inputs
Includes audio and alarm outputs for recording of sound and integration into an existing alarm system

Recorder:

4-Channel Network Video Recorder
NVR connects to your router, and picks up the cameras on your network

4MP Recorder
Capable of recording at 2688×1520 resolution, so you won’t lose any of the stunning detail from the cameras

Hard Drive Storage
Includes your choice of pre-installed hard drive for storing footage

HDMI Output
easily connect recorder to an HD TV or monitor using standard cable

Remote Access
View live cameras or recordings from anywhere in the world using apps for PC, phone or tablet

Alarm In/Out
CCTV connects to an existing alarm system, letting the devices trigger each other

The Video as well as Audio Input
IP video input:		4-ch
Network
Incoming bandwidth:		50Mbps
Outgoing bandwidth:		40Mbps

Video/Audio Output
HDMI/VGA output:		1-ch, resolution: 1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
Decoding
Decoding format:		H.265+/H.265/ H.264+/H.264
Capability:		1-ch @ 4 MP / 2-ch @ 1080p

Hard Disk
Interface Type:		1 SATA interface
SATA:		1 SATA interface for 1 HDD
Capacity:		Up to 6TB capacity for each HDD
External Interface
Network Interface:		1 RJ-45 10 / 100 Mbps self adaptive Ethernet interface
USB Interface:		2, USB2.0

General
Power Supply:		12 VDC
Working Temperature:		-10 oC ~ +55 oC (+14 oF~ + 131 oF)
Working Humidity:		10 % ~ 90 %
Dimensions:		260 × 246 × 48 mm (10.2″ × 9.7″ × 1.9″)
Weight(without HDD):		≤ 1 kg (2.2 lb)

Image Sensor:				1/2.8″ Progressive Scan CMOS
Min. Illumination:				Color: 0.01 Lux @(F1.2; AGC ON), 0.028 Lux @(F2.0; AGC ON)
Shutter time:				1/3 s to 1/100,000 s
Slow shutter:				Yes
Lens:				2.8 mm Horizontal FOV: 114.5°, vertical FOV: 62°, diagonal FOV: 135.5°
Lens Mount:				M12
Adjustment Range:				Pan: 0° to 360°, tilt: -90° to 90°, rotate: 0° to 90°
Day& Night:				IR Cut Filter
Wide Dynamic Range:				Digital WDR
Compression Standard
Video Compression:			H.264+/H.264/MJPEG
H.264 code profile:			Baseline Profile/Main Profile
Video bit rate:			32Kbps~8Mbps
Audio Compression:			G.711/G.722.1/G.726/MP2L2/PCM
Audio bit rate:			64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32 to 160Kbps(MP2L2)

Max. Image Resolution:		1920 x 1080
Frame Rate:		50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub Stream:		50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) 60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement:		BLC/3D DNR
Image Settings:		Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Day/Night Switch:		Auto/Scheduled/Day/Night
Network
Alarm Trigger:		Motion detection, video tampering alarm, illegal login
Protocols:		TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, IPv6, UDP, QoS, Bonjour
General Function:		Heartbeat, mirror, password protection, privacy mask, watermark

Interface
Communication Interface:		1 RJ45 10M/100M self-adaptive Ethernet port
Audio:		1 Built-in mic, mono sound
Audio
Environment Noise Filtering:		Support
Audio Sampling Rate:		8 kHz/16 kHz

Wi-Fi Specification (-W)
Wireless Standards:		IEEE802.11b, 802.11g, 802.11n
Frequency Range:		2.4 GHz ~ 2.4835 GHz
Channel Bandwidth:		20/40MHz Support
Security:		64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmission Rate:		11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps
Wireless Range:		50m(depend on environment)
Protocols:		802.11b: CCK, DQPSK, DBPSK 802.11g/n: 64-QAM, 16-QAM, QPSK, BPSK
General
IR Range:		Up to 30 m
Operation Condition:		-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply:		12 VDC ± 25%, PoE (802.3at, class 4), Φ 5.5 mm coaxial power plug
Power Consumption:		12 VDC, 0.4 A, Max: 5 W
Weather Proof:		IP66
Dimensions:		Camera: 99 mm × 68 mm × 66 mm (3.9″ × 2.7″ × 2.6″) With package: 172 mm × 110 mm × 99 mm (6.8″ × 4.3″ × 3.9″)
Weight:		Camera: 272 g (0.6 lb.) With package: 517 g (1.1 lb.)
